Plum Flower Head Pan Head Machine Screw in Stainless Steel 304

  • Model NO.: M2-M8
  • Type: Plum Flower Head
  • Connection: Common Bolt
  • Standard: DIN, GB
  • Trademark: OEM
  • Specification: M2 to M8
  • HS Code: 731815
  • Material: Stainless Steel
  • Groove: Plum Flower
  • Head Style: Plum Flower Pan Head
  • Grade: 4.8
  • Transport Package: Plastic Bag, Carton, Pallet
  • Origin: Jiangsu, China
Quantity:
Plum flower head Pan head machine screw in stainless steel 304

Product name: Plum flower head Pan head machine screw
Standard: DIN,GB
Material: SUS304
Head type: Plum flower Pan head
Diameter size:M2-M8
Length: 3mm to 60mm
Application: machinery

Plum Flower Head Pan Head Machine Screw in Stainless Steel 304
                                                                                                         Unit:mm
Model M2 M2.5 M3 M4 M5 M6
p 0.4 0.45 0.5 0.7 0.8 1
dk 3.7-4 4.7-5 5.3-5.6 7.64-8 9.14-9.5 11.57-12
k 1.46-1.6 1.96-2.1 2.06-2.4 2.92-3.1 3.52-3.7 4.3-4.6
Slot T6 T8 T10 T20 T25 T30
t 0.63-0.77 0.91-1.04 1.01-1.27 1.27-1.66 1.52-1.92 2.02-2.42
d 1.89-1.98 2.38-2.48 2.87-2.98 3.84-3.98 4.83-4.97 5.82-5.97
The above parameters for your reference.
Please inform the the model and length when you send the inquiry, like M2*5,  thank you!
